ExchangeForecast.com is a site that gives a fun forecasting of several exchange rates for tomorrow, 3 days later, and a week later, using neural network to predict and genetic algorithm to find its best parameters.

Neural Network

As predictor, we use ensemble of feedforward neural networks with back-propagation learning:
  • The ensemble has:
    • the population number of networks from genetic algorithm,
    • each network has its own fitness value, only those having fitness > 1 are included into ensemble,
    • the final prediction is weighted average of all network predictions:
        final = (w0*p0 + w1*p1 + ..)/(w0 + w1 + ..)
        but excluding outliers using weighted median absolute deviation method, and
    • the weight is defined as logarithm of fitness: ln(fitness).
  • The neural network has:
    • an input layer with WNDOW.length nodes,
    • a hidden layer with HIDDENS nodes, and
    • an output layer with 1 node.
  • As input it uses:
    • WNDOW.length points window of previous normalized rates in specified positions,
    • for example, in position 1, 2, 5, 8, 10 before predicted point, etc.
    • hence, input layer has WNDOW.length nodes.
  • The normalized rate of point i is defined as
      norm[i] = ln(rate[i]/rate[i-1])
    This way, we use the degree of change instead of absolute rate, hence the variance in currencies can be scaled down, thus stabilize the training result.
  • The training of neural network is performed with:
    • AdaDelta algorithm with L2 decay = L2_DECAY, and
    • batch size = BATCH_SIZE ‰ (permil) of training size,
    • trained with latest data set from the past exchange rates, with
    • training size is SIZE_K x neural network size, and
    • no validation is performed to save time.
  • Neural network size can be calculated as:
      net size = (input nodes + 1)*(hidden nodes) + (hidden nodes + 1)*(output nodes)
    • For example, with above nodes:
        net size = (WNDOW.length + 1)*HIDDENS + (HIDDENS + 1)*1
        training size = SIZE_K * net size
        batch size = BATCH_SIZE * training size / 1000

Genetic Algorithm

Further, we use genetic algorithm optimization technique to find the best parameters for above neural network:
  • Parameters to optimize are:
    • Number of nodes in input layer (also window size and positions). [3 ~ 13]
    • Number of nodes in hidden layer. [3 ~ 23]
    • Value of L to define L2 decay as 10-L. [0 ~ 5]
    • Value of batch size in ‰ (permil) of training size. [1 ~ 999]
    • Multiplier of training size to network size. [3 ~ 13]
  • The chromosome type is binary chromosome, such that all parameters that are integer, are going to be converted to binary representation back and forth during evolution.
  • The crossover type is one point crossover with crossover rate 0.9.
  • The mutation policy is binary mutation with mutation rate 0.15.
  • The selection policy is tournament selection with tournament size 3.
  • The population is elitistic population with population size 100 and elitism rate 0.1.
  • And for stopping condition, fixed generation count is used.
  • For fitness function, we use Standard Error of the Estimate (SEE) of the forecast:
    • SEE = √(Σ(rate - prediction)2N)
    • The better prediction, the lower SEE value.
    • So we inverse it to get fitness value.

Best Parameters

Genetic algorithm is used to find best parameters of neural networks, specifically for 5 top currencies and bases below.
  • a. SIZE_K
  • b. WNDOW
  • c. HIDDENS
  • d. L2_DECAY
  • f. SEE
  • h. net size
  • i. training size
  • j. batch size

For other currencies, the global best parameters are found by averaging SEE values of 5 random currencies and bases.
